Descriptor Overview

Note: “n” is an integer denoting the index of the Intel

ME VSCC table.

Bits Description

31:24 Reserved

23:16

SPI Component Device ID 1. This field identifies the second byte of the Device ID of the SPI

Flash Component. This is the third byte returned by the Read JEDEC-ID command (opcode 9Fh).

15:8

SPI Component Device ID 0. This field identifies the first byte of the Device ID of the SPI Flash

Component. This is the second byte returned by the Read JEDEC-ID command (opcode 9Fh).

7:0

SPI Component Vendor ID. This field identifies the one byte Vendor ID of the SPI Flash

Component. This is the first byte returned by the Read JEDEC-ID command (opcode 9Fh).
