Intel Confidential
APPENDIX A - Descriptor Configuration
A.18 PCHSTRP16—Strap 16 Record (Flash Descriptor
Records)
Flash Address: FPSBA + 040h Size: 32 bits
Default Flash Address: 140h
Recommended Value:
A.19 PCHSTRP17—Strap 17 Record (Flash Descriptor
Records)
Flash Address: FPSBA + 044h Size: 32 bits
Default Flash Address: 144h
Recommended Value:
A.20 PCHSTRP18—Strap 18 Record (Flash Descriptor
Records)
Flash Address: FPSBA + 048h Size: 32 bits
Default Flash Address: 148h
Recommended Value:
Bits Description Usage
31:0 Reserved, set to ’0’
Bits Description Usage
31:2 Reserved, set to ’0’
1 Chipset configuration. set to’1’b
0 Integrated System Clock/ External Clock Select
0 = Integrated System Clock (default)
1 = External Clock
Bits Description Usage
31:0 Reserved, set to ’0’
