Intel® Server Board S1200BT TPS Appendix B: Integrated BMC Sensor Tables
Revision 1.0
Intel order number G13326-003
123
Full Sensor Name
(Sensor name in SDR)
Sensor #
Platform
Applicability
Sensor Type
Event/Reading Type
Event Offset Triggers
Contrib. To System
Status
Assert/De-
assert
Readable
Value/Offsets
Event
Data
Rearm
Stand-by
02 - Power down
03 - Power cycle
08 - Timer interrupt
Physical Security
(Physical Scrty)
04h
Chassis
Intrusion is
chassis-
specific
Physical
Security
05h
Sensor Specific
6Fh
00 - Chassis intrusion
OK
As and
De
–
Trig
Offset
A
X
04 - LAN leash lost
FP Interrupt
(FP NMI Diag Int)
05h
Chassis -
specific
Critical
Interrupt
13h
Sensor Specific
6Fh
00 - Front panel NMI /
diagnostic interrupt
OK
As
–
Trig
Offset
A
–
SMI Timeout
(SMI Timeout)
06h
All
SMI Timeout
F3h
Digital Discrete
03h
01 – State asserted
Fatal
As and
De
–
Trig
Offset
A
–
System Event Log
(System Event Log)
07h
All
Event
Logging
Disabled
10h
Sensor Specific
6Fh
02 - Log area reset /
cleared
OK
As
–
Trig
Offset
A
X
System Event
(System Event)
08h
All
System
Event
12h
Sensor Specific
6Fh
04 – PEF action
OK
As
-
Trig
Offset
A
X
Button Sensor
(Button)
09h
All
Button/Switc
h
14h
Sensor Specific
6Fh
00 – Power Button
02 – Reset Button
OK
AS
_
Trig
Offset
A
X
PCH Thermal Trip
(PCH Therm Trip)
0Dh
All
Temperature
01h
Digital Discrete
03h
01 – State Asserted
Fatal
As and
De
–
Trig
Offset
M
X
Baseboard
Temperature 1
(Baseboard Temp)
20h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Front Panel
Temperature
(Front Panel Temp)
21h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
PCH
TemperatureNote1
(PCH Temp)
22h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
