Intel S1200BTS User Manual

Appendix B: Integrated BMC Sensor Tables Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
124
Full Sensor Name
(Sensor name in SDR)
Sensor #
Platform
Applicability
Sensor Type
Event/Reading Type
Event Offset Triggers
Contrib. To System
Status
Assert/De-
assert
Readable
Value/Offsets
Event
Data
Rearm
Stand-by
Baseboard
Temperature 3
(Inlet Temp)
24h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Hot-swap Backplane
Temperature
(HSBP Temp)
29h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Fan Tachometer
Sensors
(Chassis specific
sensor names)
30h–
34h
Chassis-
specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc = Degraded
c = Non-fatal2
As and
De
Analog
R, T
M
-
Power Supply 1
Status
(PS1 Status)
50h
Chassis-
specific
Power
Supply
08h
Sensor Specific
6Fh
00 - Presence
OK
As and
De
–
Trig
Offset
A
X
01 - Failure
Degraded
02 – Predictive Failure
Degraded
03 - A/C lost
Degraded
06 – Configuration
error
OK
Power Supply 2
Status
(PS2 Status)
51h
Chassis-
specific
Power
Supply
08h
Sensor Specific
6Fh
00 - Presence
OK
As and
De
–
Trig
Offset
A
X
01 - Failure
Degraded
02 – Predictive Failure
Degraded
03 - A/C lost
Degraded
06 – Configuration
error
OK
Power Supply 1
AC Power Input
(PS1 Power In)
54h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Power Supply 2
AC Power Input
(PS2 Power In)
55h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Power Supply 1
+12V % of Maximum
Current Output
(PS1 Curr Out %)
58h
Chassis-
specific
Current
03h
Threshold
01h
[u] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
