Intel® Server Board S1200BT TPS Appendix B: Integrated BMC Sensor Tables
Revision 1.0
Intel order number G13326-003
127
Full Sensor Name
(Sensor name in SDR)
Sensor #
Platform
Applicability
Sensor Type
Event/Reading Type
Event Offset Triggers
Contrib. To System
Status
Assert/De-
assert
Readable
Value/Offsets
Event
Data
Rearm
Stand-by
Baseboard
Processor Vcc
(BB P1 Vcc)
E0h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
–
Baseboard
Processor VccUSA
(BB P1 VccUSA)
E1h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
–
Baseboard +1.05V
PCH
(BB +1.05V PCH)
E2h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
–
Baseboard +1.05V
Auxiliary
(BB +1.05V AUX)
E3h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Baseboard +1.35V
VDDQ
(BB +1.35V P1
MEM)
E4h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
–
Baseboard +12.0V
V1
(BB +12.0V V1)
E8h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
–
Baseboard +1.5V
Auxiliary
(BB +1.5V AUX)
E9h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As and
De
Analog
R, T
A
X
Hard Disk Drive 0
Status
(HDD 0 Status)
F0h
Chassis-
specific
Drive Slot
0Dh
Sensor Specific
6Fh
00 - Drive Presence
OK
As and
De
–
Trig
Offset
A
X
01- Drive Fault
Degraded
02- Predictive Failure
Degraded
07 - Rebuild/Remap in
progress
Degraded
Hard Disk Drive 1
Status
(HDD 1 Status)
F1h
Chassis-
specific
Drive Slot
0Dh
Sensor Specific
6Fh
00 - Drive Presence
OK
As and
De
–
Trig
Offset
A
X
01- Drive Fault
Degraded
02- Predictive Failure
Degraded

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
