Intel S1200BTS User Manual

Appendix B: Integrated BMC Sensor Tables Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
128
Full Sensor Name
(Sensor name in SDR)
Sensor #
Platform
Applicability
Sensor Type
Event/Reading Type
Event Offset Triggers
Contrib. To System
Status
Assert/De-
assert
Readable
Value/Offsets
Event
Data
Rearm
Stand-by
07 - Rebuild/Remap in
progress
Degraded
Hard Disk Drive 2
Status
(HDD 2 Status)
F2h
Chassis-
specific
Drive Slot
0Dh
Sensor Specific
6Fh
00 - Drive Presence
OK
As and
De
–
Trig
Offset
A
X
01- Drive Fault
Degraded
02- Predictive Failure
Degraded
07 - Rebuild/Remap in
progress
Degraded
Hard Disk Drive 3
Status
(HDD 3 Status)
F3h
Chassis-
specific
Drive Slot
0Dh
Sensor Specific
6Fh
00 - Drive Presence
OK
As and
De
–
Trig
Offset
A
01- Drive Fault
Degraded
02- Predictive Failure
Degraded
07 - Rebuild/Remap in
progress
Degraded

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
