Intel S5500BC Product Specification

Connector / Header Locations and Pin-outs Intel
®
Server Board S5500BC TPS
Intel order number: E42249-003 Revision 1.0
52
5. Connector / Header Locations and Pin-outs
5.1 Board Connectors
Table 10. Board Connector Matrix
Connector Quantity Reference Designators Connector Type
Pin
Count
Memory 8 J1D1,J1D2,J1D3,J1D4,J8K2,J8K1,J9K2,J9
K3
DDR3 DIMM Sockets 240x8
PCI Express* x8 3 J4B1,J4B2,J5B1 Card Edge 98x3
PCI Express* x4 1 J2B2 Card Edge 64
PCI 32/33 1 J3B1 Card Edge 120
SATA 6 J1B4,J1B3,J1A2,J1B1,J1B2,J2B1 App-specific Plug 7x6
SGPIO 1 J1C1 Header 4
IPMB 2 J8B1 Header 4
HSBP 1 J9B1 Header 4
Fans 5 J3K1,J7K2,J3K2,J8K3,J8B4 Header 4x5
RMM3 1 J3C1 RMM3 connector 34
Power Supply 3 J9B3
J7K1
J9E1
Header 24
8
5
USB 4 J1A3
J2A2
J5A1
J6A1
Dual USB/LAN Connector on
the rear panel; dual USB
headers on the board
10
10
22
22
VGA 1 J7A1 Connector 15
Serial Port 2 J8A1
J9A1
DB-9 rear connector
2x5 Header
9
10
GigE 2 J5A1
J6A1
USB/LAN combo connector 22
22
Front Panel 1 J9E2 Header 24
SATA Key 1 J7B1 Header 3
Intrusion Detect 1 J8B3 Header 2
Battery
1
Battery Holder
2
5.2 Power Connectors
The main power supply connection has an SSI-compliant 2x12 pin connector (J9B3) and two
additional power-related connectors: one SSI-compliant 2x4 pin power connector (J7K1) that
