Server Board S5500BC TPS Regulatory and Certification Information

Revision 1.0 Intel order number: E42249-003 79

9.2 Product Regulatory Compliance Markings

The server board is provided with the following regulatory marks.

Regulatory Compliance Region Marking

UL Mark USA/Canada

CE Mark Europe

EMC Marking (Class A) Canada CANADA ICES-003 CLASS A

D33025

BSMI Marking

(Class A)

Taiwan

C-tick Marking Australia / New Zealand

N232

RRL MIC Mark Korea

인증번호: CPU-Model Name (A)

Country of Origin Exporting Requirements MADE IN xxxxx (Provided by label, not silk

screen)

Model Designation Regulatory Identification Examples (Intel

Server Board S5500BC) for

boxed type boards; or Board PB number for non-

boxed boards (typically high-end boards)

PB Free Marking? Environmental

Requirements

Refer to the spec

http://prodregs.intel.com/ProductCertifications/Servers/

GG-1035%20spec%20Rev%2002.pdf

China RoHS Marking China
