Intel S5500BC Product Specification

Connector / Header Locations and Pin-outs Intel
®
Server Board S5500BC TPS
Intel order number: E42249-003 Revision 1.0
54
Table 13. EPS12V 1x5 Connector (J9E1)
Pin Signal Name Signal Name
1 SMB_PWR_3V3SB_CLK White
2 SMB_PWR_3V3SB_DAT Yellow
3 NC N/A
4 GND Black
5 3.3V SENSE+ Orange
5.3 Riser Card Slot
The Intel
®
Sever Board S5500BC has one riser card slot (J4B2). The riser card slot supports
one low-profile half-length PCI Express* 2.0 x8 add-in card.
Table 14. Low-profile PCI Riser Card Pin-out (J3C1)
Pin Name Slot Name Pin
B1 12V PRSNT1# A1
B2 12V 12V A2
B3 12V 12V A3
B4 GND GND A4
B5 SMCLK JTAG2 A5
B6 SMDATA JTAG3 A6
B7 GND INTRU# A7
B8 3.3V JTAG5 A8
B9 JTAG1 3.3V A9
B10 3.3VAux 3.3V A10
B11 WAKE# PERST# A11
Key
B12 3.3V GND A12
B13 GND REFCLK1+ A13
B14 PETxP0 REFCLK1- A14
B15 PETxN0 GND A15
B16 GND PERxP0 A16
B17 PRSNT2# PERxN0 A17
B18 GND GND A18
B19 PETxP1 3.3V A19
B20 PETxN1 GND A20
B21 GND PERxP1 A21
B22 GND PERxN1 A22
B23 PETxP2 GND A23
B24 PETxN2 GND A24
B25 GND PERxP2 A25
B26 GND PERxN2 A26
B27 PETxP3 GND A27
B28 PETxN3 GND A28
B29 GND PERxP3 A29
B30 3.3V PERxN3 A30
B31 PRSNT2# GND A31
B32 GND A32
B33 PETxP4 A33
