Server Board S5500BC TPS Connector / Header Locations and Pin-outs

Revision 1.0 Intel order number: E42249-003 57

Table 17. VGA Connector Pin-out (J7A1)

Pin Signal Name

1 VGA_RED

2 VGA_GREEN

3 VGA_BLUE

4 RESERVED

5 GND

6 GND

7 GND

8 GND

9 5V

10 GND

11 RESERVED

12 DDCDAT

13 HSYNC

14 VSYNC

15 DDCCLK

5.6.2 SATA II Connectors

The Intel

Server Board S5500BC provides six Serial ATA connectors (J1B4, J1B3, J1A2, J1B1,

J1B2, and J2B1).

Table 18. SATA Connector Pin-out (J1B4, J1B3, J1A2, J1B1, J1B2, and J2B1)

Pin Signal Name Description

1 GND GND1

2 SATA#_TX_P_C Positive side of transmit differential pair

3 SATA#_TX_N_C Negative side of transmit differential pair

4 GND GND2

5 SATA#_RX_N_C Negative side of Receive differential pair

6 SATA#_RX_P_C Positive side of Receive differential pair

7 GND GND3
