Connector / Header Locations and Pin-outs
Intel
®
Server Board S5500BC TPS
Intel order number: E42249-003
Revision 1.0
62
5.11
SATA RAID Key Header
Table 27. SATA connector Pin-out (J7B1)
Pin
Signal Name
1 GND
2 FM_ICH_RAID_KEY
3 GND
5.12 IPMB
Header
Table 28. IPMB Connector Pin-out (J8B1)
Pin Signal
Name
1 SMB_IPMB_5VSB_DAT
2 GND
3 SMB_IPMB_5VSB_CLK
4 P5V_STBY
