Server Board S5500BC TPS Connector / Header Locations and Pin-outs
Revision 1.0 Intel order number: E42249-003 53
supports an additional 12 V and one SSI-compliant 1x5 pin connector (J9C1) that provides I
2
C
monitors the power supply.
Table 11. EPS12V 2x12 Connector (J9B3)
Pin Signal Name Color Pin Signal Name Color
1 +3.3V Orange 13 +3.3V Orange
2 +3.3V Orange 14 -12V Blue
3 GND Black 15 GND Black
4 +5V Red 16 PS_ON Green
5 GND Black 17 GND Black
6 +5V Red 18 GND Black
7 GND Black 19 GND Black
8 PWR_GD Gray 20 NC N/A
9 5VSB Purple 21 +5V Red
10 +12V Yellow 22 +5V Red
11 +12V Yellow 23 +5V Red
12 +3.3V Orange 24 GND Black
Table 12. EPS12V 2x4 Connector (J7K1)
Pin Signal Name Color Pin Signal Name Color
1 GND Black 5 +12V Yellow
2 GND Black 6 +12V Yellow
3 GND Black 7 +12V Yellow
4 GND Black 8 +12V Yellow
