Thin Mini-ITX
Internal E
lectrical Inter
faces
Thin Min
i-ITX Based PC Syst
em Design
Guide
25
Pin
Signal
Pin
Signal
7
Ground
8
Ground
9
Key (no pin)
10
No Connect
2.5.2
Internal Dual USB
2.0
Header
Internal dual USB 2.0 header shall
be
2x5, 2.54mm pitch, keyed at pins 9 and 10.
Figure 2-9. 2x5 USB 2.0 Header (Keyed at Pins 9 and 10)
Table 2-
10
. 2x5 USB 2.0 Header (Keyed at Pins 9 and 10
)
P
in
-Out
Pin
Signal
Pin
Signal
1
+5V DC
2
+5V DC
3
Data (negative)
4
Data (negative)
5
Data (positi
ve)
6
Data (positi
ve)
7
Ground
8
Ground
9
Key (no pin)
10
Key (no pin)
24
26
