Page #67 background image
Reference System Layouts
Thin Mini-ITX Based PC System Design Guide 67
Cederview Power Thermal Utility Rev 1.2 Settings:
o CPU Thermal Stress
Run “Thermal Test”
The Graphics Workload will be set to a default
All two core CPU workloads will be set to same
percentage
o Memory Thermal Stress Test
Run 3Dmark06*. Only run the SM2.0 Graphics Test module in
continuous loop
GT1 Return to Proxicon
GT2 Firefly Forest
7.3.3 Temperature Measurement Locations
The air temperature entering both sides of the CPU blower and a DRAM chip from the
top and bottom side of each bank of SO-DIMM is measured using thermocouples.
Intel’s motherboards have various system component temperature sensors. The
highest of the CPU DTS sensor values, the PCH die sensor, memory sensor, Hard Disk
Drive sensor, and the voltage regulator board temperature sensor values are recorded
during testing.
