Thin Mini-ITX Internal Electrical Interfaces
Thin Mini-ITX Based PC System Design Guide 27
Table 2-12. 2x10 USB 3.0 Header Pin-Out
Pin
Signal
Description
1
Vbus
Power
2
IntA_P1_SSRX-
USB3 ICC Port1 SuperSpeed Rx-
3
IntA_P1_SSRX+
USB3 ICC Port1 SuperSpeed Rx+
4
GND
Ground
5
IntA_P1_SSTX-
USB3 ICC Port1 SuperSpeed Tx-
6
IntA_P1_SSTX+
USB3 ICC Port1 SuperSpeed Tx+
7
GND
Ground
8
IntA_P1_D-
USB3 ICC Port1 D- (USB2 Signal D-)
9
IntA_P1_D+
USB3 ICC Port1 D- (USB2 Signal D+)
10
ID
Over Current Protection
11
IntA_P2_D+
USB3 ICC Port2 D+ (USB2 Signal D+)
12
IntA_P2_D-
USB3 ICC Port2 D- (USB2 Signal D-)
13
GND
Ground
14
IntA_P2_SSTX+
USB3 ICC Port2 SuperSpeed Tx+
15
IntA_P2_SSTX-
USB3 ICC Port2 SuperSpeed Tx-
16
GND
Ground
17
IntA_P2_SSRX+
USB3 ICC Port2 SuperSpeed Rx+
18
IntA_P2_SSRX-
USB3 ICC Port2 SuperSpeed Rx-
19
Vbus
Power
20
Key
Not Connected
