Intel WAPD-235N User Manual

Getting Started for Admin
Content Access Point
User Manual November 2016
12
1 System LED status
2 3G/4G/LTE LED status
3 Power button
4 Factory reset button
5 Wall-mount holes
6 Wi-Fi MAC (WFM), Ethernet (LNM) MAC address label
7 microSD slot (model WAPD-237N
1
only)
8 Power plug
9 WAN Ethernet port
10 WAN Ethernet link LED status
11 WAN Ethernet activity LED status
12 USB 3.0 port
13 3G/4G/LTE cellular modem
14 Hard drive
15 3G/4G/LTE micro-SIM slot
16 Battery
2.3.1 LEDs
Table 1: System LED status
Device state Color Description
Off None The device is powered off
Fast pulsing then solid Blue The device is powered on and booting up
Slow pulsing (“breathing”) Blue The device has booted and is functioning normally
Slow pulsing Blue and orange Battery low
Solid Orange System error/warning
Table 2: 3G/4G/LTE LED status
Device state Color Description
Off None 3G/4G/LTE off
On Blue 3G/4G/LTE on
Blinking Blue No signal
Table 3: WAN Ethernet LED status
LED Color Description
Activity Off No activity
Green Receive
Orange Transmit
Link Off No link
Green Link
2.3.2 Buttons
Table 4: Power button
Device state Action Result
Off Press and hold for 2 seconds Turns on
On Press once Turns off
Table 5: Factory reset button
Device state Action Result
On Press and hold for 5 seconds System LED flashes and device goes through reset process
2.3.3 Ports
The device has four ports:
• WAN Gigabit Ethernet
• USB 3.0 (USB 2.0 compatible)
• Micro-SIM (accessible by removing bottom cover)
• microSD (model WAPD-237N
1
only)
