v240M – Marine Satellite Communication System
32
Figure 23. Fasten the Reector and the Base Frame using M16x35L Hex Bolts
M16 x 35L M16 Spring Washer
+
M16 Flat Washer
Stable Mount
After putting the Reector and the Base Frame together, they should be fastened using
three M16x35L hex bolts as shown in gure 23.
Tool(Stable mount jig)
