OPERATION INSTRUCTION

DVB VERIFY SKEW OFFSET

DVB DECODE +0.0

7. Edit satellite DVB VERIFY* method and SKEW OFFSET.

DVB VERIFY will be only activated and applied when DVB mode of TRACKING

SIGNAL is chosen to be used. Press the UP and DOWN arrow keys to select DVB VERIFY

and press the OK key to set the parameter.

DVB VERIFY1*

• AGC – use signal level for satellite tracking.

• DVB Lock – use DVB Lock for satellite tracking.

• DVB Decode – use DVB Decode for satellite tracking.

• DSS Decode – use DSS Decode for satellite tracking.

RX POL TX POL

HORI. VERT.

8. Set RX POL and TX POL

To select the polarity for both RX (receive ) and TX (transmit ).

Press the UP and DOWN arrow keys to select VERTICAL, HORIZONTAL, RHCP, or LHCP.

SAT. TYPE KU : VERTICAL, HORIZONTAL

SAT.TYPE C : VERTICAL, HORIZONTAL, RHCP, or LHCP

Press the OK key to set the parameter.

DVB FREQ. SYMBOL NID

04080MHz 27500KSps 0X0888

9. Set DVB FREQUENCY, SYMBOL RATE and NID when the DVB mode of TRACKING

SIGNAL is selected.

45,000 is the maximum allowed symbol rate value. NID (network ID) range is from

0x000 to 0xFFFF (hexadecimal digit).

Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).

Press the UP and DOWN arrow keys to increase or decrease the value. Or press the NUM-

BER keys to set the desired value directly. Press the OK key to set the parameter.

DVB veriy method

Set polarity

Set DVB tracking

frequency

Intellian v240M User Manual
