17
Recommended Power Supply Cables
Power supply cables must not run parallel to logic level wiring as noise will
be coupled onto the logic signals from the power supply cables. If more
than one driver is to be connected to the same power supply, run separate
power and ground leads to each driver from the power supply. The
following Belden cables (or equivalent) are recommended for use with the
IB series drive.
Twisted Pair Jacketed
<4 Amps DC......................... Belden part# 9740 or equivalent 18 AWG
>4 Amps DC......................... Belden part# 8471 or equivalent 16 AWG
AC Line Filtering
The output voltage of an unregulated power supply will vary with the AC
input applied. It is recommended that an AC line filter be used to prevent
damage to the IB series drive due to a lightning strike or power surge.
WARNING! Verify that the power supply wiring is correct prior to
power application. If +V and GND are connected in reverse
order, catastrophic damage to the drive may occur! Ensure that
the power supply output voltage does not exceed the maximum
rated voltage for your IB driver!
WARNING! Hazardous voltage levels may be present if using an
open frame power supply to power the IB driver!
