APPendix C
Miscellaneous Accessories
TS-6 Screw Terminal Set
The TS-6 screw terminal set is available as
an option for the IB series drivers. These
six position terminal blocks plug directly
onto the IB drive connector pins.
There are two of the six position
terminals per set.
When using the TS-6 screw terminals the
following practices should be observed:
Wire Size .................................................................... 14 to 22 AWG
Wire Strip Length....................................................0.238” (6.0 mm)
Tightening Torque ................................................ 7 lb-in (0.79 N-m)
