46
Recommended IMS Power Supplies
IP404/IP404-240†
Unregulated Linear Supply
Range
Input 120 VAC Version .................................... 102-132 VAC
240 VAC Version .................................... 204-264 VAC
No Load Output Voltage* ............................... 43 VDC @ 0 Amps
Continuous Output Rating* ........................... 32 VDC @ 2 Amps
Peak Output Rating* ......................................... 26 VDC @ 4 Amps
* Measurements taken at 25°C, 120 VAC, 60 Hz.
†
Optional 240 VAC Version
Recommended IMS Motors
IMS stocks the following 1.8° hybrid stepping motors that are recom-
mended for the IB463. All IMS motors are CE marked. For more
detailed information on these motors please see the IMS catalog or web
site at www.imshome.com.
17 Frame Motors
Single Shaft Double Shaft
M2-1713-S .................................................................... M2-1713-D
M2-1715-S .................................................................... M2-1715-D
M2-1719-S .................................................................... M2-1719-D
23 Frame Motors
Single Shaft Double Shaft
M2-2215-S .................................................................... M2-2215-D
M2-2220-S .................................................................... M2-2220-D
M2-2232-S .................................................................... M2-2232-D
M2-2240-S .................................................................... M2-2240-D
IMS also carries a new series of 23 frame enhanced stepping motors that
are recommended for use with the IB463. These motors use a unique
relationship between the rotor and stator to generate more torque per
frame size while ensuring more precise positioning and increased accuracy.
The special design allows the motors to provide higher torque than
standard stepping motors while maintaining a steadier torque and
reducing torque drop-off.
