51
Recommended IMS Power Supplies
IP804/IP804-240†
Unregulated Linear Supply
Range
Input 120 VAC Version .................................... 102-132 VAC
240 VAC Version .................................... 204-264 VAC
No Load Output Voltage* ............................... 76 VDC @ 0 Amps
Continuous Output Rating* ........................... 65 VDC @ 2 Amps
Peak Output Rating* ......................................... 58 VDC @ 4 Amps
ISP300-7/ISP300H-7†
Unregulated Switching Supply
Range
Input 120 VAC Version .................................... 102-132 VAC
240 VAC Version .................................... 204-264 VAC
No Load Output Voltage* ............................... 68 VDC @ 0 Amps
Continuous Output Rating* ........................... 63 VDC @ 2 Amps
Peak Output Rating* ......................................... 59 VDC @ 4 Amps
* Measurements taken at 25°C, 120 VAC, 60 Hz.
†
Optional 240 VAC Version
