IntelliSAW CAM-5 User Manual

User Manual
May 2018 910.00382.0001
17
2.3.6 SD Micro Connector
Interface
Name
Description
SD Micro
SD Micro
SD card for factory use only
2.3.7 SCADA Connectors
SCADA interface is determined by model number.
2.3.7.1 Modbus RTU Connector
Pin
Name
Description
DATA-
DATA Negative
Negative Input for Modbus RTU (RS485)
DATA-
DATA Negative
Redundant Negative Input for Modbus RTU (RS485)
DATA+
DATA Positive
Positive Input for Modbus RTU (RS485)
DATA+
DATA Positive
Redundant Positive Input for Modbus RTU (RS485)
D-COM
DATA Common
Common input for Modbus RTU (RS485)
D-COM
DATA Common
Redundant Common input for Modbus RTU (RS485)
2.3.7.2 Ethernet Connector
Interface
Name
Description
RJ45
Ethernet (ETH-2)
Used for SCADA communication (10/100 BASE-T)
2.3.7.3 Fiber Connector
Interface
Name
Description
LC
FIBER (100Base-FX)
Used for SCADA communication
