User Manual
May 2018 910.00382.0001
19
2.3.11 Relay Alarm Connector
Pin
Name
Description
A-COM
Alarm Common
Common output for Alarms Connector
A-NO1
Alarm Output 1
Normally Open Alarm Output 1
A-NC1
Alarm Output 1
Normally Closed Alarm Output 1
A-NO2
Alarm Output 2
Normally Open Alarm Output 2
A-NC2
Alarm Output 2
Normally Closed Alarm Output 2
A-NO3
Alarm Output 3
Normally Open Alarm Output 3
A-NC3
Alarm Output 3
Normally Closed Alarm Output 3
A-NO4
Alarm Output 4
Normally Open Alarm Output 4
A-NC4
Alarm Output 4
Normally Closed Alarm Output 4
A-NO5
Alarm Output 5
Normally Open Alarm Output 5
A-NC5
Alarm Output 5
Normally Closed Alarm Output 5
A-NO6
Alarm Output 6
Normally Open Alarm Output 6
A-NC6
Alarm Output 6
Normally Closed Alarm Output 6
A-COM may be high side with grounded loads (current source through relays) or may be low side with
powered loads (current sink through relays).
