3.4 Air Interface Connections
The IntelliSAW Air Interfaces are shipped with a cable assembly.
The CAM-5 supports up to 4 Air Interface connections (Port 1 to Port 4) through female SMA
connections. Only IntelliSAW provided Air Interfaces are suitable for the desired performance and for
compliance with transmitter authorizations. For more details, reference the (910.00379.001) IntelliSAW
Sensor Installation Manual.
WARNING
RF CABLES MUST BE KEPT AWAY FROM ALL MEDIUM VOLTAGE CONDUCTORS AND ANY
LOW VOLTAGE CONDUCTORS EXCEEDING 300V
AC
.
THE SEPARATION REQUIRED FOR REINFORCED ISOLATION IS THE GREATER OF THE
VALUES REQUIRED BY IEC62271 “NO TEST” BIL SPACINGS AND THE DISTANCE REQUIRED BY
LOCAL CODE. FAILURE TO MAINTAIN THIS SPACING CAN RESULT IN ARC FLASH, PROPERTY
DAMAGE, PERSONAL INJURY, AND LOSS OF LIFE.
Failure to follow the instructions given can result in death or serious injury
