Section 1 Introduction
The IntelliSAW CAM™-5 provides a local human machine interface (HMI) with remote monitoring
capabilities (temperature, partial discharge, and humidity / ambient temperature), data trending and
alarming, data aggregation, and multiple communication interfaces such as Modbus TCP, DNP-3, and
IEC61850 to integrate into existing SCADA / DCS systems.
The CAM-5 can be a stand-alone system ideal for predictive condition-based monitoring of electrical
power critical assets such as switchgear, generator circuit breakers, and bus ducts.
This manual covers CAM-5 functionality, configuration, safety, and installation.
1.1 Models
The following tables outline available CAM-5 models.
Model Number
Description
CAM5B-TPH-AMEU
CAM5 Base:
- Monitoring: Temperature, PD, Ambient Temp &Humidity
- Alarm outputs – 6 ch. (NO/NC)
- Multiunit Device Interface (RS485)
- Communication interface: Ethernet
- Standard communication: Modbus TCP
- Universal Input Power (100 to 250 VAC; 120 to 250VDC
1
)
CAM5B-T00-AMEU
CAM5 Base:
- Monitoring: Temperature
- Alarm outputs – 6 ch. (NO/NC)
- Multiunit Device Interface (RS485)
- Communication interface: Ethernet
- Standard communication: Modbus TCP
- Universal Input Power (100 to 250 VAC; 120 to 250VDC
1
)
CAM5B-000-AMEU
CAM5 Base:
- No Monitoring
- Alarm outputs – 6 ch. (NO/NC)
- Multiunit Device Interface (RS485)
- Communication interface: Ethernet
- Standard communication: Modbus TCP
- Universal Input Power (100 to 250 VAC; 120 to 250VDC
1
)
CAM5B-TPH-AMFU
CAM5 Base:
- Monitoring: Temperature, PD, Ambient Temp & Humidity
- Alarm outputs – 6 ch. (NO/NC)
- Multiunit Device Interface (RS485)
- Communication Interface: Fiber Optic (100 base FX)
- Standard communication: Modbus
- Universal Input Power (100 to 250 VAC; 120 to 250VDC
1
)
CAM5B-T0H-AMEU
CAM5 Base:
- Monitoring: Temperature, Ambient Temp &Humidity
- Alarm outputs – 6 ch. (NO/NC)
- Multiunit Device Interface (RS485)
- Communication interface: Ethernet
- Standard communication: Modbus TCP
- Universal Input Power (100 to 250 VAC; 120 to 250VDC
1
)
1
DC operation has not been evaluated for FCC Part 15 or c/UL/IEC 61010-1.

IntelliSAW CAM-5 Specifications

General

Brand	IntelliSAW
Model	CAM-5
Category	Measuring Instruments
Language	English
