IntelliSAW CAM-5 User Manual

User Manual
May 2018 910.00382.0001
61
501
Alpha SD 3
CAM5_RdrNN/SdaSPDC03$MX$UhfPaDsch$mag$f
502
Alpha SD 4
CAM5_RdrNN/SdaSPDC04$MX$UhfPaDsch$mag$f
503
Alpha PD 1
CAM5_RdrNN/PdaSPDC01$MX$UhfPaDsch$mag$f
504
Alpha PD 2
CAM5_RdrNN/PdaSPDC02$MX$UhfPaDsch$mag$f
505
Alpha PD 3
CAM5_RdrNN/PdaSPDC03$MX$UhfPaDsch$mag$f
506
Alpha PD 4
CAM5_RdrNN/PdaSPDC04$MX$UhfPaDsch$mag$f
507
Beta SD 1
CAM5_RdrNN/SdbSPDC01$MX$UhfPaDsch$mag$f
508
Beta SD 2
CAM5_RdrNN/SdbSPDC02$MX$UhfPaDsch$mag$f
509
Beta SD 3
CAM5_RdrNN/SdbSPDC03$MX$UhfPaDsch$mag$f
510
Beta SD 4
CAM5_RdrNN/SdbSPDC04$MX$UhfPaDsch$mag$f
511
Beta PD 1
CAM5_RdrNN/PdbSPDC01$MX$UhfPaDsch$mag$f
512
Beta PD 2
CAM5_RdrNN/PdbSPDC02$MX$UhfPaDsch$mag$f
513
Beta PD 3
CAM5_RdrNN/PdbSPDC03$MX$UhfPaDsch$mag$f
514
Beta PD 4
CAM5_RdrNN/PdbSPDC04$MX$UhfPaDsch$mag$f
515
Phi SD 1
CAM5_RdrNN/SdpSPDC01$MX$UhfPaDsch$mag$f
516
Phi SD 2
CAM5_RdrNN/SdpSPDC02$MX$UhfPaDsch$mag$f
517
Phi SD 3
CAM5_RdrNN/SdpSPDC03$MX$UhfPaDsch$mag$f
518
Phi SD 4
CAM5_RdrNN/SdpSPDC04$MX$UhfPaDsch$mag$f
519
Phi PD 1
CAM5_RdrNN/PdpSPDC01$MX$UhfPaDsch$mag$f
520
Phi PD 2
CAM5_RdrNN/PdpSPDC02$MX$UhfPaDsch$mag$f
521
Phi PD 3
CAM5_RdrNN/PdpSPDC03$MX$UhfPaDsch$mag$f
522
Phi PD 4
CAM5_RdrNN/PdpSPDC04$MX$UhfPaDsch$mag$f
NN = 01 to 10 Readers
7.3.3 Mapping of Digital Output to IEC61850
Relay No
IEC61850 Mapping
1
CAM5_Dop/StsGGIO01$ST$Alm1$stVal
2
CAM5_Dop/StsGGIO01$ST$Alm2$stVal
3
CAM5_Dop/StsGGIO01$ST$Alm3$stVal
4
CAM5_Dop/StsGGIO01$ST$Alm4$stVal
5
CAM5_Dop/StsGGIO01$ST$Alm5$stVal
6
CAM5_Dop/StsGGIO01$ST$Alm6$stVal
