D-0120578-C – 2019/11
Eclipse – Instructions for Use - US
Page 91
The ear side symbol and color are written on the top of the graph.
The checkmarks indicate the TE bars there have met the criteria as set in the protocol, as show above
for the right ear.
The TE bars having no checkmark did not meet the TE criterion and can be either below the noise or
absent.
The grey area is the ambient background noise in the TE test.
