SW500 Wired Scale System
700431
Rev G, December 2021
Page 10
INDICATOR OVERVIEW
Scale Controls (continued)
BACKLIGHT
Press the BACKLIGHT key to turn the backlight on and off.
PRINT (SERIAL OUTPUT)
Press the PRINT key to access the PRINT Menu. Press the 1 key to print the screen.
The print format displayed will be the same as the last active screen format used. The
following screenshot is an example of a print layout.
Press the 2 key to access the PRINTING OPTIONS Menu. The following menu is
displayed.
In this example, Print Option 1 - TOGGLE CONTINUOUS (continuous serial output) is
disabled (OFF). The serial output is an externally available signal that can drive a
numeric overhead display, a computer RS-232 input or other peripheral devices
To select the continuous serial output setting, press the 1 key. Four settings are
available to select from. Refer to the following table for the available setting functions.
SETTING FUNCTION
OFF Continuous output disabled. Print screen enabled
MULTI-LINE Continuous output enabled, multi-line format
TOTAL ONLY Continuous output enabled, total only format
13-LINE Continuous output enabled, 13-line format
INTERCOMP, U.S.A.
TEL: 763-476-2531
ACTUAL LBS
LF 232 RF 222
LR 241 RR 206
LEFT 52.50% C 51.39%
REAR 49.61% T 901
PRINTING OPTIONS
1: TOGGLE CONTINUOUS
(OFF )
2: SELECT BAUD RATE
