OPERATION
Special Displays (continued)
JAPAN VERSION
Simultaneously press the LF key, 2 key and CLEAR key to toggle the JAPAN display
format. Turn the scale off and then turn on the scale back on. The following screenshot
will be displayed.
Press the 1 key to select the Free Scaling option. Press the 2 key to select the Fixed
Scaling option.
FREE SCALING
The FREE SCALING display format displays each individual wheel weight, the total
weight of the selected scales, the percentage of the selected weight to total weight and
the total weight. An example of a Free Scaling Display Format is shown below.
FIXED SCALING
The FIXED SCALING display format displays each individual wheel weight, the total of
the front end, the total of the left side, the cross percentage and the total weight. An
example of a Fixed Scaling Display Format is shown below.
SELECT RACING TYPE
1:FREE SCALING
2:FIXED SCALING
750 725
950 525 A
SELECT: 1675 56.78%
TOTAL: 2950 lbs
Selected
Total
Selected
Weight
750 725 lb
950 525 A
FRONT 1475 C 56.78%
LEFT 1700 2950
