OPERATION
HUB MODE ENTRIES
1. Turn the indicator and scales on.
2. Press the ZERO key and PRINT key to access the HUB Mode Menu. The HUB
MODE menu item will be displayed as either OFF (disable) or ON (enabled).
3. Press the 3 key to access the HUB MODE screen.
1) Press the 1 key to toggle the HUB MODE ON.
ATTENTION: When HUB MODE has been enabled (turned ON), the
message "HUB COMPENSATION ENABLED!" will be displayed briefly at
power-up when the indicator is turned on. The message is a reminder that
the system is operating in HUB MODE and the weights are being
compensated accordingly.
2) Press the 2 key to enter the Tire Assembly weights and Hub Plate weights. A
prompt will be displayed to enter each of the (4) Tire Assembly weights
individually. When the tire assembly weights have been entered, a prompt will be
displayed to enter each of the (4) Hub Plate weights individually. When the hub
plate weights have been entered the display will return to the HUB MODE screen
1. SWITCH lb/kg
2. READ ONLY (OFF)
3. HUB MODE(OFF)
(HIT ACTUAL TO EXIT)
1. HUB COMP (OFF)
2. ENTER TIRE/HUB PLT
(HIT ACTUAL TO EXIT)
