OPERATION
KART OVERVIEW
The SW500 Wired Scale System is designed to independently measure the force
applied by each tire of a kart. The measurement is referred to as the ACTUAL weight
applied by each tire. Corner weights can be entered which will be displayed as the
TARGET weight. The COMPARE weight values equate the amount of weight that
needs to be added or subtracted to a CORNER weight to achieve the TARGET weight.
For example, when the COMPARE value displayed is a negative (-) value, the ACTUAL
weight is greater than the TARGET weight.
The SW500 Wired Scale System can also perform a number of calculations
automatically. In lieu of displaying the wheel weights (Actual, Target or Compare), the
weights can be displayed as a percentage of the total weight or as a percentage and
weight. Additionally, scales can be selected in groups (for example; left front and left
rear, or left rear and right front) and the scale will calculate the percentage of the total
weight that applies to the selected grouping of scales.
The scale has eight default display modes.
DEFAULT MODE DESCRIPTION
OVAL TRACK
The following parameters are displayed: Individual Wheel
Weight, Left Side %, Rear %, Cross %, Total Weight
KART
The following parameters are displayed: Individual Wheel
Weight, Left Side %, Front %, Cross %, Total Weight
ROAD RACING
Selection #3 (Road Racing) is a dynamic display format to
select the wheel weights to be totaled and displayed as
Selected Weight. Individual Wheel Weight, Selected Weight,
Selected % to Total Weight and Total Weight are displayed
DIRT TRACK
The following parameters are displayed: left wheel weight and
%, rear weight and %, cross weight and %, Rear Bite
DRAG/RALLY
The following parameters are displayed: Each Wheel Weight,
Front %, Rear % and Total Weight
WHEELS AND
PERCENTAGES
The following parameters are displayed: Each Wheel Weight,
Front Right %, Left %, Right %, Wedge, Right Rear % and
Total Weight
TOTAL
TOTAL option will provide a quick snapshot of the total weight
applied to all of the scales in the system.
TOTAL + 4
TOTAL + 4 option provides the total weight on all of the scales
and displays the individual weight applied to each scale
