SW500 Wired Scale System
700431
Rev G, December 2021
Page 20
OPERATION
QUICK START NORMAL MODE
Arrange the scales as described in the SETUP section referenced on previous page.
Turn the indicator on. Turn the scales on. The copyright screen will be briefly displayed
followed by the Change Display Format screen. To display the Copyright screen for an
extended view, press and hold the ON key when turning the indicator on.
1:OVAL 5:DRAG/RALLY
2:CUP/NW 6:WHT+%
3:ROAD RACE 7: TOTAL
4:DIRT TRK 8: TOTAL + 4
ATTENTION: If using a SW777RFX Pro Kart scale, menu item #2 will be
displayed as KART instead of CUP/NW.
All formats referenced in the menu are fixed display formats with the exception of menu
item #3, ROAD RACE. ROAD RACE is a dynamic display format providing the
capability to select which wheel weights will be totaled and displayed as the selected
weight.
DISPLAY LAYOUT
LINES 1-2
Four weights displayed on the first two lines are individual wheel weights. The weights
are displayed in the same pattern as the wheels are installed on the car; Left Front,
Right Front, Left Rear, Right Rear.
A specific scale can be selected or removed by pressing the LF, RF, LR, RR key. Each
time a position key is pressed, a select arrow will turn on and off on the right side of the
weight displayed for a specific scale.
LINE 3
The third line displays the selected weight and the percentage of selected weight to the
total weight.
LINE 4
The fourth line displays the total weight on all four scales.
