Intercomp SW500 - Specifications; Environmental Specifications; Physical Specifications

SW500 Wired Scale System
700431 Rev G, December 2021
Page 8
SPECIFICATIONS
ENVIRONMENTAL
FUNCTION DESCRIPTION
Humidity
10 to 95% non-condensing
Temperature
Operating +14 F to +104 F / -10 C to +40 C
Storage -40 F to +170 F / -40 C to +75 C
PHYSICAL
ITEM DESCRIPTION SPECIFICATION
Standard and Motorcycle
Scale
Dimensions
15 in x 15 in x 2.5 in / 381 mm X 381 mm
X 635 mm
Weight 23 lb / 10.5 kg
SW 8.8K and 20K Scale
Dimensions
15 in x 15 in x 4 in / 381 mm x 381 mm x
100 mm
Weight 35 lb / 15.9 kg
SW Kart Scale
Dimensions
10 in x 10 in x 2 in / 254 mm x 254 mm x
510 mm
Weight 6.6 lbs / 3.0 kg
Indicator (with cables)
Dimensions
11 in x 8 in x 2.7 in / 279 mm x 203 mm x
685 mm
Weight 8 lbs / 3.6 kg
Carrying Case
Dimensions
17 in x 11 in x 7 in / 432 mm x 279 mm x
178 mm
Material ABS structural foam
