SW500 Wired Scale System
700431
Rev G, December 2021
Page 38
SERIAL OUTPUT
13-LINE CONTINUOUS OUTPUT
The 13-Line Continuous Output option will transmit 13 pieces of data continuously in a
repeating pattern. The following example shows a 13-Line continuous output
transmission.
0 XXXX.X Notes: ASCII <cr> and <lf> follow the weight.
1 XXXX.X The decimal place is used only if required.
2 XXXX.X
3 XXXX.X
4 XXXX.X
5 XXXX.X
6 XXXX.X
7 XXXX.X
8 XXXX.X
9 XXXX.X
: XXXX.X
; XXXX.X
< XXXX.X
The first character of each line is the Data Identifier. The next group of characters
(XXXX.X) follow the data identifier and reference the weight for the specific data
description. Refer to the following table for each data identifier and the corresponding
weight description. For example, Data Identifier 0 represents the weight for the Left
Front.
DATA
IDENTIFIER
DATA
DATA
IDENTIFIER
DATA
0 Left Front 7 Rear
1 Right Front 8 Front Bite
2 Left Rear 9 Rear Bite
3 Right Rear : Cross
4 Left Side : Total
5 Right Side < Total Selected
6 Front
ATTENTION: It is important to note that each line of data will be preceded by
an ESC (0x1B) character and a ~ (0X7E) character. The data transmitted will
be the actual weights regardless of the mode selected (Actual, Target or
Compare).
