SW500 Wired Scale System
700431
Rev G, December 2021
Page 32
OPERATION
Special Displays (continued)
RF-LF CROSS VERSION
Simultaneously press the LF key, 2 key and CLEAR key to toggle the RF-LF CROSS
version display format. The RF-LF Cross formula is the RF Weight minus the LF
Weight. Turn the scale off and then turn the scale back on. The following screenshot
will be displayed.
When the RF-LF Cross format is selected, the indicator will automatically display the
WEIGH Mode. Refer to the following screenshot. There are no other display formats
available for viewing. The display information displayed includes each individual wheel
weight, the RF - LF Cross weight and the total weight.
750 800 lb
950 525 A
RF-LF CROSS: 50
