INDICATOR OVERVIEW
Baseline Setup (continued)
8. Enter a memory location (1-99) to save the target setup entry.
9. The screen will return to Normal weighing mode.
The screen will display the targets entered. Press the ACTUAL key or the
COMPARE key to view the actual weight on the scales or to compare the targets
entered to the actual weights on the scales.
2: WEDGE
Manually entering values in Wedge format enables targets to be entered with respect
following parameters: Total Weight, Left Side %, Rear % and Wedge %.
1. Press the STORE/ENTER key to enter a target setup.
2. Enter setting 00. Press the STORE/ENTER key.
3. Press the 2 key to select the Wedge format.
4. Enter the Total Weight.
5. Enter the Left Side %.
6. Enter the Rear %.
7. Enter the Wedge %.
8. Enter a memory location (1-99) to save the target setup entry.
9. The screen will return to Normal weighing mode.
The screen will display the targets entered. Press the ACTUAL key or the
COMPARE key to view the actual weight on the scales or to compare the targets
entered to the actual weights on the scales.
