SPECIFICATIONS
OPTIONS

EXCITATION
Voltage – VDC 5 or 10
Current – MAX – mA 180
OUTPUTS
Serial Interface USB 2.0
Output – Analog, 16 bit – VDC Scalable, ±10
Output – Analog, Direct – Hz 1.5K BW
Output – Analog – mA 4–20 (oponal)
Limits Quad-programmable
PERFORMANCE
Maximum Display Counts ±999,999
Display Update / sec. 15 Hz
Internal Resoluon – bits 24
Signal Input Range – mV/V ±4.5
Programmable Count – by 1, 2, 5, 10, and 20
Conversion Rate / sec. 60
Maximum Error – %FS 0.01 ±1 count
CMRR – dB 115

Operang Temperature
°F +32 to +122
°C 0 to +50
Storage Temperature
°F +14 to +140
°C -10 to +60
Relave Humidity – % MAX
°F 95 (104) non-condensing
°C 95 (40) non-condensing

AC Power – VAC, Hz 115 or 230, 50–60
DC Power (opon) Available as a special
Power Consumpon – was 120VAC, 2A; 230VAC, 1A
MECHANICAL
Dimensions – W x H x D
in 17 x 5.25 x 10 (19 w/L-Brackets)
mm 431.8 x 133.35 x 254 (482.6 w/L-Brackets)
Weight
lbs 9
kg 4.08233
Display
(2) Interacve 7" graphical touch screen
displays
Unit Annunciator
Lb, Kg, Klb, kN, N, mV/V,
lbf-in, oz-in, Nm
• TEDS Plug & Play Ready! IEE1451.4 compliant
• 4 channel
• Remote sense excitaon
• 5 & 6 point linearizaon
• Bipolar
• ±999,999 display counts
• Nonlinearity < ±0.005%
• Auto setup for mulple load cells
• Fast, direct analog output
• ±10 VDC scalable analog output – 16 bit
• USB 2.0 serial communicaon
• Peak/valley hold with front panel reset
• Front panel and remote tare
• 8 selectable digital lters
• Auto zero
• Front panel shunt calibraon with two selectable
resistors
• Display units conversion: Lb, Kg, N, Psi, Mpa, Klb, KN,
t, mV/V, lb-in, oz-in, Nm
• (2) Interacve 7" graphical touch screen displays
• Quadrature encoder channel available
• mV/V calibraon
• Compable with Gold Standard® Calibraon Systems
• Up to three addional 16-bit scalable analog outputs
• Display Freeze/Remote Display Freeze
• 4-20 mA analog output
• Quad Limits
• RS485
• Mul-drop RS232
• 7-pin circular load cell connector
• Encoder Channel
• Keylock
• High level input channel

• 9840-400-1-T 115 VAC
• 9840-400-2-T 230 VAC
Datasheet GLD-SYS-9840 15-331 v1.4 05-28-2020
