Interface GOLD STANDARD User Manual

7418 East Helm Drive • Scosdale, Arizona 85260 • 480.948.5555 • www.interfaceforce.com
Page 38 of 45
STRIP JACKET
BACK 7 / 16
4X 1 / 8
TRIM OFF SHIELD 1 / 16 MAX
STRIP JACKET BACK 1
7X 1 / 8
"L"
2. CLIP WHT/YEL WIRE BOTH ENDS.
1 "L" = LENGTH IN FEET.
INSTRUMENT END
LOAD CELL END
1
(21336) 1 / 8 X 1 / 2
SHRINK TUBE (2 REQ)
(20274) 1 / 16 SHRINK
TUBE (9 REQ)
FOLD BACK SHIELD SOLDER ORANGE WIRE TO SHIELD, TRIM OFF
SHIELD TO MINIMIZE LUMP
REMOVE MYLAR WRAP BOTH ENDS
7 CONDUCTOR CABLE (20203)
(25010) 3 / 16 SHRINK
TUBE (1 REQ)
DE-9P
(25053)
PC06A-10-6S
(21313)
9 SHIELD
D
B
C
A
BLACK
WHT/BLK
GREEN
WHITE
RED
RED/WHT
WHT/YEL
6 - EXCITATION
5 - SENSE 3 + SIGNAL
4 - SIGNAL
1 + EXCITATION
2 + SENSE
A B
C D
CC CT
CC = COMPRESSION UPSCALE CT = TENSION UPSCALE
PC06A-10-6S (SR)
SOLDER SIDE
(21313)
F
E
D
C
B
A
DE-9P
SOLDER SIDE
(25053)
1 2 3 4 5
6 7 8 9
HOOD (21396)
SCALE:
SIZE:
DWG. NO:
A
SHEET OF
REV:
DATE
CREATOR
DESIGNED:
DETAILED:
Interface Inc. claims proprietary rights in the information disclosed hereon. This
drawing is furnished in confidence on the express understanding that neither it nor
any reproduction thereof will be disclosed to others or used for the purpose of
manufacture or procurement of the article or part shown hereon without written
permission of Interface Inc. The drawing shall remain the property of Interface Inc.
and shall be returned upon request by Interface In
c.
7401 E. BUTHERUS DR. SCOTTSDALE, AZ USA 85260
REVISIONS
REV
DESCRIPTION
DATE
APPROVED
TITLE:
RG
10/12/98
CC/CT-173-XX INTERCONNECT
12679
D
NONE
CAD FILE <N:\~\12679D.SLD***>
1 1
REMOVE BURRS AND SHARP EDGES .02 MAX SURFACE FINISH 63 MICROINCHES
12679
CABLE MODEL 9840 TO STD. LOAD CELL
CAM DATA:
A
INITIAL RELEASE 10/14/98
10/16/98
ADDED PIN P/N 21397
B
05/04/99
CORRECTED COLOR CODE
C
02/15/13
CLIP WHT/YEL, 25053 WAS 21395
D
