Appendix A — Technical Specifications
130 EasyCoder PF2i Bar Code Label Printer User’s Guide (Fingerprint Version)
Sensors
Gap/Mark/Out of Media Yes 5 fixed positions
Printhead Lifted Yes
Ribbon End Thermal transfer
model only
Controls
Control Lamps 3
Display 2 x 16 character LCD Background light
Keyboard 22 keys membrane-
switch
Print button 1
Beeper Yes
Data Interfaces
Serial 1 x RS-232 +
1 x USB
Bar Code Wand Yes
Connection for Optional
Interface Boards
1 + 1 1 for EasyLAN, 1 for
other board
Memory Card Adapter 1 CompactFlash cards
Accessories and Options
Transfer Ribbon Mechanism Option
Integral Self-strip Unit with Liner
Takeup
Option For peel-off operation
Rotating Media Supply Hub Option Replaces supply post
3-inch Adapter Option
Short Side Door Option
1
Long Side Door Option
1
Label Taken Sensor Option
Real Time Clock Option 10+ years life
RS-232 Cable Option
Parallel Interface Cable Option
