Appendix B — Media Specifications
140 EasyCoder PF2i Bar Code Label Printer User’s Guide (Fingerprint Version)
Tickets with Black Mark
⇐ a ⇒ Media Width
Maximum: 60.0 mm (2.36 inches)
Minimum (standard): 25.0 mm (1.00 inches)
Minimum (quick-load): 40.0 mm (1.57 inches)
⇐ b ⇒ Copy Length
Minimum: 20.0 mm (0.8 inches)
Maximum: depends on SDRAM size
⇐ c ⇒ LSS Detection Position
Five fixed positions, see “Label Stop Sensor (LSS) Position
Adjustment” on page 118.
⇐ d ⇒ Black Mark Width
a
TICKETS & TAGS
FEED
DIRECTION
b
e
d
c
