Appendix B — Media Specifications
EasyCoder PF2i Bar Code Label Printer User’s Guide (Fingerprint Version) 139
Under ideal circumstances, a minimum ticket length of 4 mm
(0.16 inches) could be used. It requires the sum of the copy
length (b) and the detection slit height (e) to be larger than 7 mm
(0.28 inches), that batch printing is used, and that no pull back
of the media is performed. Intermec does not guarantee that such
short tickets will work, but it is up to the user to test this in his
unique application.
⇐ c ⇒ LSS Detection Position
Five fixed positions, see “Label Stop Sensor (LSS) Position
Adjustment” on page 118.
⇐ d ⇒ Detection Slit Length
The length of the detection slit (excluding corner radii) must be
minimum 2.5 mm (0.10 inches) on either side of the LSS
detection position (e).
⇐ e ⇒ Detection Slit Height
Maximum: 21.3 mm (0.83 inches)
Recommended: 1.6 mm (0.06 inches)
Minimum: 1.2 mm (0.05 inches)
Media Type Setup
• Ticket (with gaps)
Note: Do not allow any perforation to break the edge of the
media as this may cause the media to split and jam the printer.
