Appendix C — Interfaces
148 EasyCoder PF2i Bar Code Label Printer User’s Guide (Fingerprint Version)
• Double Serial Interface Board (device "uart2:" and "uart3:")
• Serial/Industrial Interface Board (device "uart2:")
• IEEE 1284 Parallel Interface Board (device "centronics:")
Regardless of if any Parallel Interface Board is installed, the
printer can also be fitted with one of the following EasyLAN
interface boards for connection to a Local Area Network (LAN):
• EasyLAN Ethernet Interface (device "net1:")
• EasyLAN Wireless Interface (device "net1:")
Double Serial Interface Board
“uart3:”
RS-232,
RS-422 non isolated,
or 20 mA current loop
“uart2:”
RS-232,
RS-422 non isolated,
RS-422 isolated,
or RS-485
