Appendix A — Specifications
PF8d/PF8t Printers User’s Guide 35
Internal Interface
PF8t Specifications
Pin UART1 Wafer Ethernet Module
1N.CN.C
2 TXD RXD
3RXDTXD
4 CTS RTS
5 GND GND
6 RTS CTS
7 E_MD E_MD
8 RTS CTS
9 E_RST E_RST
10 +5V +5V
11 GND GND
12 +5V +5V
General Specifications
Resolution 8 dot/mm (203 dpi) or 12 dot/mm (300 dpi)
Print Mode Direct Thermal/Thermal Transfer
CPU 32 bit
Memory 4 MB CompactFlash, 8 MB SDRAM
Print Speed 203 dpi: 2, 3, and 4 ips
300 dpi: 1 or 2 ips
Print Length 203 dpi: Maximum 1727 mm (68.0 in)
Minimum 12 mm (0.47 in)
300 dpi: Maximum 900 mm (35.43 in)
Minimum 12 mm (0.47 in)
Print Width Maximum 104 mm (4.09 in)
Sensor Type Adjustable reflective sensor. Fixed transmissive
sensor, center-aligned.
Sensor Detection Label gap and black mark sensing, label length
autosensing or program command setting.
Media Label roll outside diameter: Maximum 127
mm (5.00 in)
Core diameter: 25 mm, 38 mm (1 in, 1.5 in)
Width: 25 mm to 118 mm (1 in to 4.65 in)
Thickness: 0.05 to 0.18 mm (.0025 to .0098
in)
