Appendix A — Specifications
38 PF8d/PF8t Printers User’s Guide
Handshake: DSTB connects to the printer, BUSY connects to
the host.
Interface cable: Parallel cable compatible with computer.
12 /Paper empty printer
13 /Select printer
14 /Auto line feed host/printer
15 N/C
16 N/C
17 N/C
18 +5V, max 500ma
19-30 Signal GND host
31 /Initialize host/printer
32 /Error printer
33 Signal GND
34-35 N/C
36 /Select in host/printer
Parallel Interface (continued)
Pin Function Transmitter
Internal Interface UART1
Pin UART1 Wafer Ethernet Module
1N.CN.C
2 TXD RXD
3RXDTXD
4 CTS RTS
5 GND GND
6 RTS CTS
7 E_MD E_MD
8 RTS CTS
9 E_RST E_RST
10 +5V +5V
11 GND GND
12 +5V +5V
