Intermec SG20T User Manual

Chapter 1 — Introducing the SG20T Tethered Scanner
6 SG20T Tethered Scanner User’s Guide
Accessories
There are several different accessories available. Here you will find a
list of required and optional accessories.
Required Accessories
You will need one or more of the following cables for your SG20T.
Optional Accessories
The following accessories are optional.
SG20T Cable List
Cable Part Number
USB cable (6 feet straight) CAB-SG20-USBxxx
Keyboard wedge cable (6 feet "Y" straight) CAB-SG20-KBWxxx
RS232 Cable, DB9 (6 feet straight) CAB-SG20-SERxxx
Universal Intermec power supply 5V 851-089-xxx
Note: A power cord is also needed to plug in the power supply. The
power cord needed depends on your country and is sold separately.
SG20T Optional Accessories
Cable Part Number
Desktop / Wall Mount Holder-SG20-xx
Desktop Adjustable Stand Stand-SG20-xx

Intermec SG20T Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Optical sensor resolution	- pixels
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Product color	Gray
Built-in display	No
International Protection (IP) code	IP30
Input voltage	5 V
Power consumption	120 mA
Power source type	DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	200 mm
Width	61 mm
Height	65 mm
Weight	125 g
