Chapter 2 — Scanning with the SG20T
12 SG20T Tethered Scanner User’s Guide
Understanding the Beeps
The SG20T also beeps to give you audio feedback when performing
some functions. For example, you hear a beep each time you scan a
valid bar code.
Scanning Bar Codes
The SG20T contains either a 1D linear imager (SG20T1D) or 2D area
imager (SG20THP or SG20THC) to scan bar code data. The type of
scan engine you are using and the type of bar code you are decoding
determines the way you scan the bar code.
When you unpack the SG20T, these bar code symbologies are enabled:
• Code 39
• Code 128 / GS1-128
• EAN/UPC
• PDF417 (SG20THP and SG20THPHC only)
• DataMatrix (SG20THP and SG20THPHC only)
Default SG20T Beep Descriptions
Beep Sequence What it Means
Two beeps Power-up
Single beep The scanner successfully scanned a bar code.
Two fast beeps Configuration bar code successfully scanned
Six very fast beeps Transmission error
OR
Configuration bar code was not accepted
For the SG20THP and SG20THPHC do not look directly into the
window area or at a reflection of the laser framing beam while
scanning. Long-term exposure to the laser framing beam can
damage your vision.

Intermec SG20T Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Optical sensor resolution	- pixels
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Product color	Gray
Built-in display	No
International Protection (IP) code	IP30
Input voltage	5 V
Power consumption	120 mA
Power source type	DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	200 mm
Width	61 mm
Height	65 mm
Weight	125 g
