Chapter 4 — Configuring the SG20T Scanner
30 SG20T Tethered Scanner User’s Guide
Configuring Predefined Imager Modes
When using a 2D model (SG20THP or SG20THC), you can optimize
the reading performance of the scanner by adjusting certain
parameters. Since there are many parameters that can be adjusted, we
recommend using the pre-defined imager settings to quickly set up
your imager for optimized reading. The pre-defined imager settings
take in to account the type of bar code, environment and reading
surface.
There are 4 pre-defined imager settings:
• 1-Dimensional bar codes only
• Standard 1-dimensional and 2-dimensional bar codes
• 1-Dimensional and 2-dimensional bar codes in a bright
environment
• 1-Dimensional and 2-dimensional bar codes with reflective
surface (shiny labels)
Select the pre-defined imager setting that best suits your needs:
1D bar codes only
Standard 1D and 2D bar codes (*)
Standard 1D and 2D bar codes, bright environment
Standard 1D and 2D bar codes, reflective surface

Intermec SG20T Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Optical sensor resolution	- pixels
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Product color	Gray
Built-in display	No
International Protection (IP) code	IP30
Input voltage	5 V
Power consumption	120 mA
Power source type	DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	200 mm
Width	61 mm
Height	65 mm
Weight	125 g
