Intermec SG20T User Manual

Chapter 4 — Configuring the SG20T Scanner
SG20T Tethered Scanner User’s Guide 31
DPM Mode
Direct Product Marking (DPM) is when the bar code is marked
directly on the product. Enabling DPM Mode when scanning DPM
bar codes optimizes reading this type of code.
DPM mode - Enable
DPM mode - Disable (*)
Configuring Your System with EasySet
EasySet is an Intermec configuration application that provides you
with two ways to configure your scanner.
• Online setup—send configuration commands from EasySet
directly to the product.
• Offline setup—send configuration commands to a bar code setup
sheet, print the setup sheet and use a connected scanner to scan
the bar codes.
EasySet is available on the Intermec web site at www.intermec.com/
EasySet. Simply download and install.
Online Setup with EasySet
Online setup with EasySet is only available if you are using an RS-232
cable or a USB cable.
To configure your scanner online by sending commands from EasySet
1 Connect the scanner to a host PC using an RS-232 or USB cable
and set connection parameters if necessary.
Note: DPM mode is not required to be able to read DPM bar codes
but may be necessary when scanning hard to read DPM bar codes.

Intermec SG20T Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Optical sensor resolution	- pixels
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Product color	Gray
Built-in display	No
International Protection (IP) code	IP30
Input voltage	5 V
Power consumption	120 mA
Power source type	DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	200 mm
Width	61 mm
Height	65 mm
Weight	125 g
