Product information
Holding brake (zero motion hold)
The RollerDrive EC310 is equipped with an electronic holding brake that allows it to be used in sloped and ascending
conveyors. For this, the RollerDrive is held in position if no start signal is issued. If the power supply system fails, the
Energy recovery system
The RollerDrive recovers energy when braking the conveyed material. This results in the motor and motor electronics
heating up less and improves the energy balance of the system. The Interroll controls are equipped with a circuit that
prevents an increase of voltage in the power supply.
If motor controls are used without a voltage limiter (brake chopper), it must be ensured that the power
supply units used are suitable for energy recovery.
3.3 Rating plate
RollerDrive as intended.
Rating plate
1 Manufacturer 5 Rated voltage
2 Date of manufacture 6 Speed range
3 Gear ratio 7 RollerDrive type
4 Output 8 Serial number
